Forklift Starters

Forklift Starters - Today's starter motor is typically a permanent-magnet composition or a series-parallel wound direct current electrical motor together with a starter solenoid installed on it. Once current from the starting battery is applied to the solenoid, basically via a key-operated switch, the solenoid engages a lever which pushes out the drive pinion which is located on the driveshaft and meshes the pinion utilizing the starter ring gear that is found on the engine flywheel.

As soon as the starter motor begins to turn, the solenoid closes the high-current contacts. When the engine has started, the solenoid has a key operated switch which opens the spring assembly to pull the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This allows the pinion to transmit drive in only a single direction. Drive is transmitted in this particular method via the pinion to the flywheel ring gear. The pinion continuous to be engaged, for instance as the driver fails to release the key as soon as the engine starts or if the solenoid remains engaged because there is a short. This actually causes the pinion to spin separately of its driveshaft.

This above mentioned action prevents the engine from driving the starter. This is actually an essential step as this particular type of back drive would enable the starter to spin very fast that it can fly apart. Unless modifications were done, the sprag clutch arrangement would stop using the starter as a generator if it was used in the hybrid scheme discussed earlier. Normally a standard starter motor is designed for intermittent utilization that will prevent it being utilized as a generator.

Hence, the electrical parts are designed to operate for roughly under 30 seconds to prevent overheating. The overheating results from very slow dissipation of heat due to ohmic losses. The electrical parts are designed to save cost and weight. This is truly the reason the majority of owner's guidebooks meant for automobiles recommend the driver to stop for at least 10 seconds after each and every ten or fifteen seconds of cranking the engine, whenever trying to start an engine that does not turn over at once.

In the early 1960s, this overrunning-clutch pinion arrangement was phased onto the market. Before that time, a Bendix drive was utilized. The Bendix system operates by placing the starter drive pinion on a helically cut driveshaft. Once the starter motor starts turning, the inertia of the drive pinion assembly enables it to ride forward on the helix, thus engaging with the ring gear. When the engine starts, the backdrive caused from the ring gear allows the pinion to surpass the rotating speed of the starter. At this moment, the drive pinion is forced back down the helical shaft and therefore out of mesh with the ring gear.

In the 1930s, an intermediate development between the Bendix drive was developed. The overrunning-clutch design which was made and introduced during the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive has a latching mechanism together with a set of flyweights within the body of the drive unit. This was a lot better in view of the fact that the typical Bendix drive utilized to be able to disengage from the ring when the engine fired, even though it did not stay functioning.

The drive unit if force forward by inertia on the helical shaft as soon as the starter motor is engaged and begins turning. Next the starter motor becomes latched into the engaged position. Once the drive unit is spun at a speed higher than what is achieved by the starter motor itself, like for example it is backdriven by the running engine, and next the flyweights pull outward in a radial manner. This releases the latch and allows the overdriven drive unit to become spun out of engagement, therefore unwanted starter disengagement can be prevented before a successful engine start.
